S13series oil-immersed power transformer
Product features
1.S13 type is one independently developed product of our company which is based on S11
typetransformer, and developed through research and application of new material and new
tech-nology, and by manner of independently innovation and technology introduction.
It optimizesand designs iron core and winding structure and achieve the target of reducing
no-loadlossand noise.
2.The no-load loss decreases 37% by an average. Noise level decreases 20% comparing
tocurrent national standard JB/T 10088- -2004. Product properties has reached domestic
advancedlevel.
| Type | Rated capacity (KVA) | Connection group grade | Voltagecombination(KV) | No-loadloss | loadloss(W) | No-load current(%) | Short-clircuit resistance(%) |
| Highvoltage | Tappingrange | Lowvoltage | (W) | Dy | Yy |
| S13-M-30 | 30 | Yyn0 . Dyn11 | 6 6.3 10 10.5 11 | 土5% or 土2x2.5% | 0.4 | | 630 | 600 | 2.3 | 4.0 |
| S13-M-50 | 50 | 100 | 910 | 870 | 2.0 |
| S13-M-63 | 63 | 110 | 1090 | 1040 | 1.9 |
| S13-M-80 | 80 | 130 | 1310 | 1250 | 1.9 |
| S13-M-100 | 100 | | 1580 | 1500 | 1.8 |
| S13-M-125 | 125 | 170 | 1890 | 1800 | 1.7 |
| S13-M-160 | 160 | 200 | 2310 | 2200 | 1.6 |
| S13-M-200 | 200 | 240 | 2730 | 2600 | 1.5 |
| S13-M-250 | 250 | 290 | 3200 | 3050 | 1.4 |
| S13-M-315 | 315 | 340 | 3830 | 3650 | 1.4 |
| S13-M-400 | 400 | 410 | 4520 | 4300 | 1.3 |
| S13-M-500 | 500 | 480 | 5410 | 5150 | 1.2 |
| S13-M-630 | 630 | 570 | 6200 | 6200 | 1.1 | 4.5 |
| S13-M-800 | 800 | 700 | 7500 | 7500 | 1.0 |
| 830 | 10300 | 10300 | |
| S13-M-1000 | 1000 |
| 970 | 12000 | 1200 | 0.9 |
| S13-M-1250 | 1250 |
| S13-M-1600 | 1600 | 1170 | 14500 | 14500 | 0.8 |
| S13-M-2000 | 2000 | 1510 | 17800 | 17800 | 0.8 | Accordingto customers' requirements |
| S13-M-2500 | 2500 | 1780 | 20700 | 20700 | 0.7 |
| S13-M-3150 | 3150 | 2100 | 24300 | 24300 | 0.7 |
Technical requirements
1.Hengfengyou continues to increase investment of technical strength and modernequipment,
optimizes the production process and process constantly, has estab-lished strict and perfect
quality management standard, conducts strict moni-toring for each process from raw material
receiving inspection, production, fin-ished product inspection and warehousing, finished
products delivery toinstallation, never allows unqualified products to flow out, takes the idea
of"Zero Defect" into each detail bit by bit, ensures each process be able opass all standards,
and manufactures perfect products carefully.
2.It is our excellent internal control standard and product quality assurancesystem that makes
Hengfengyou transformer achieve favor from more andmore customers, and obtain affimation
from domestic and foreign customers,
